Case IH RD195
Features
Disc Modules
Rugged and Easy Service, Repair or Replacement
- Individually sealed bearings, gears and lubricant – damage or contamination to one disc doesn't spread to another
- Complete gear lubrication, even when cutting on slopes or at an angle
- Austempered discs for extra hardness and durability in punishing conditions
- Protective liner in the hood helps reduce rock damage
- Heavy-duty gears and cross shafts
- Individual modules protected from impact damage by a shock hub
- RD5 headers include a 3-year cutterbar warranty
Knives
Heavy Duty Knives
- Standard quick-change knives make changing or reversing knives fast and convenient
- One-bolt knives are reversible for twice the cutting life
- Knife speed of 187 mph (301 kph)
- Cutterbar angle adjusts hydraulically from 2–10 degrees below horizontal using the in-cab switch
- Knife angles available from 7 to 18 degrees to meet varying crop conditions
Shock Protection System
Extending the Life of Your Equipment
- Protects key disc module drive components when a disc encounters a field obstacle
- Easier in-field repairs
- Dramatically reduces downtime
- Lower replacement-part cost
- Standard on all rotary disc header models
| Cutting Width ft-in | 19ft 4in |
| Conditioner Type | Roll |
| Conditioner Removable | Yes |
| Min Cutting Height Range in | 0.5 |
| Max Cutting Height Range in | 3.3 |
| Header Drive | Dual hydraulic motors |
| Flotation | Hydraulic |
| Weight lb | 5754 |
| Number Of Discs | 12 |
| Knives Per Disc | 2 |
| Disc Drive Components | Bevel gearsets in individual sealed modules |
| Min Disc Speed rpm | 2600 |
| Max Disc Speed rpm | 2600 |
| Min Disc Blade Tip Speed mph | 195 |
| Max Disc Blade Tip Speed mph | 195 |
| Transition | Full width auger w/ discharge paddles |
| Roll / Rotor Length in | 102 |
| Roll / Rotor Diameter in | 10.2 |
| Roll / Rotor Speed rpm | 938 |
| Standard Roll Material | Rubber |
| Optional Roll Material | Steel |
| Roll Surface Pattern | Chevron intermeshing |
| Roll Pressure System | Torsion bar |
| Roll Adjustment Method | Crank |
