Features
Performance Features
- Available in 8-foot, 10-foot, and 12-foot widths.
- Optional tilt axle removes material on an angle for sloping, terracing and ditching.
- DSP scrapers are designed for 70 to 125 horsepower tractors
- Replaceable wear plates on the sides.
Specs
| Model | DSP10 |
| Horsepower Rating | 70 to 125 |
| Transport Width | 121-inches |
| Working Width | 120 3/16-inches |
| Capacity | 2 1/4 cu. yds. |
| Weight without material in Weight Box | |
| Tilt Axle | 1645-lb |
| No Tilt Axle | 1525-lb |
| Weight of Material in Weight Box | 760-lb |
| Depth of Box | 39-inches |
| Maximum Cutting Depth | 5-inches below grade |
| Dump Clearance | 21-inches |
| Maximum Tilt Depth To the Right | 7 5/8-inches |
| Maximum Tilt angle | 3 1/2° |
| Tongue Construction | 4-inches x 4-inches x 1/4-inch tubing |
| Side Plate Construction | 3/8-inch x 24 5/16-inches high x 39 3/4inches deep |
| Moldboard Construction | 1/4-inch x 24 1/4-inches high when formed |
| Cutting Edge | 1/2-inch x 6-inches reversible & replaceable |
| Cutting Edge Reinforcement | 3-inches x 3-inches x 5/16-inch angle plus a 1/4-inch mold board = 9/16-inch at the cutting edge. |
| Tires | New 9.5l x 15 8 PLY RIB TL on Rim 5 with 5.5 BHC |
| Maximum Transport Speed | 20 MPH |
| Lift Cylinder | 3 1/2-inches x 8-inches ASAE |
| Tilt Cylinder | 3 1/2-inches x 8-inches ASAE |
