Features
Performance Features
- Square and rectangle tube steel frames and gang tubes
- Adjustable gang angles, front and rear
- Variable Blade Spacings Available: 9” front and rear gangs for tough-to-cut “New Ground” • 7 1/2” front and rear gangs for finer soil finishing • 9” front gangs/7 1/2” rear gangs–the best of both worlds
- 1 1/8” square, high carbon steel gang axles
- Available in tractor colors
- Optional disc scrapers, Center Sweep Kit, Dual Wheel Transport Kit
Product Features
- Bearing hangers reinforces with gussets
- Notched discs for maximum cutting action
Specs
| Model Number | DHP8 |
| Drawbar horsepower requirement | 40-65 hp |
| Hitch type | Pull-type w/clevis & hole for 1 1/4” pin |
| Approximate transport width | 8’-10” |
| Max. cultivation width | 8’-6” |
| Mainframe width | 60” |
| Approx weight load on each blade (lbs.) | 95-114 |
| Disc blade sizes and types | 20” or 22” Notched |
| Disc blade spacing | 7.5” or 9” or a combination of both |
| Disc bearing type | Triple lip sealed ball bearings |
| Number of bearings | 8 |
| Forward gang angle adjustment | 15, 16.5, 18, 19.5, 21 Degrees |
| Rear gang angle adjustment | 12, 13.5, 15, 16.5, 18 Degrees |
| Hitch frame construction | 4” x 4” x 1/4” tubing |
| Side mainframe construction | 4” x 3” x 1/4” tubing |
| Mainframe Width | 60" |
| Mainframe middle tube construction | 4” x 3” x 1/4” tubing |
| Gang arm construction | 4” x 3” x 1/4” tubing |
| Gang axle | 1 1/8” Square, High Carbon Steel |
| Front to rear leveling system | Manual crank adjustment |
| Depth control | Cylinder stroke control spacers |
| Hydraulic cylinder | 3- 1/2” x 8” ASAE hydraulic cylinder |
| Transport tires and wheels | Two 9.5L x 15 tires on 15” x 6” - 5 bolt wheels |
| Parking jack | Standard |
| AVAILBLE OPTIONS | |
| Disc Scrapers, Center Sweep Kit, Dual Wheel Transport Kit |
