Features
| Benefits | Features |
| High Transport Clearance | Can go anywhere your tractor can pull it without gouging or bottoming out. |
| Large Inline End Wheels | Unmatched ground gauging in rugged terrain. Inline end wheels minimize side loading on contours and side-hills, dramatically extending the life of the no-till openers. |
| Standard Main Seedbox With 2.4 Bushels Per Foot Capacity |
The optional small seeds box and either a native grass seedbox, a fertilizer box, or a second seedbox can be added to the standard main seedbox. |
| Seed Level Indicator | Easy to read from the tractors seat and indicates the amount of left. |
| 4 Speed Gearbox For Various Seed Rates |
Makes seed rates changes quick and painless. |
| Automatic Clutch | Disengages when the drill is lifted for making end-row-turns. |
| Wide Seed Cups | Delivers the rate you choose, evenly and gently whether the seed is small, large, or fragile. |
| Calibration Crank | Makes it easier to calibrate. Eliminates need to jack up the drive tire to calibrate. |
| Grease Bank For Coulter Pivots | Makes it easier to lubricate coulter pivots frequently. |
| Rain-Tight Lids | Provides maximum seed and fertilizer protection. |
| Lock-out Hub | Disengages all drive components for reduce wear on drive system when transporting. |
| Safety Lighting | Makes it safer to transport. |
| Acremeter | Indicates the acres planted. |
| Six-Position Adjustable Hitch Height | Adjusts to your tractor’s hitch height to keep the drill level in planting position. |
| Standard Weight Brackets | Can add standard tractor weights to the weight brackets for even better penetration in tough no-till conditions. |
| Folding Tongue Option | Folds the tongue in half to use less storage space. |
Specs
| Model | 1006 | ||
| Row Spacing, Inches | 7 | 7.5 | 8 |
| Rows Per Drill | 16 | 15 | 14 |
| Approx. Weight, Pounds | 4,500 lb. (2,041 kg) | 4,300 lb. (1,950 kg) | 4,200 lb. (1,905 kg) |
| Working Width | 10 ft. (3.0 m) | ||
| Transport Width | 12 ft. 7 in (3.8 m) | ||
| Transport Height | 6 ft. 7 in (2.0 m) | ||
| Transport Length | 13 ft. 10 in (4.2 m) | ||
| Tongue Weight, Transport | 750 lb. (340 kg) | ||
| Tongue Weight, Field | 268 lb. (123 kg) | ||
| Approx. Seedbox Capacity | 23.75 bushels (836.9 l) | ||
| Small Seeds | 2.4 bushels (84.6 l) | ||
| Native Grass | 10 bushels (352.4 l) | ||
| Fertilizer | 9.2 cubic feet (260.5 l) | ||
| Dual Seed | 10 bushels (352.4 l) | ||
| End Wheel Tires | 9.00 x 24 | ||
| Tractor Requirements | 75 hp (56 kw); one remote valve | ||
