Features
| FEATURES | BENEFITS |
| Warranty | One year parts & labor. See warranty page for complete details. |
| 84" & 96" Working widths | Choice of two sizes to pick from. Both sizes handle large capacities. |
| 35 to 80 HP range for 2-Wheel Drive 35 to 65 HP range for 4- Wheel Drive |
Fits a wide variety of tractors. |
| Cat. 1 or 2 | Fits wide variety of tractors. |
| Fits Land Pride Quick-Hitch | Quick and easy attaching without leaving tractor seat. |
| 3-Way Blade | Tilt, angle and offset features available hydraulically or manually. |
| Blade angles left and right up to 40° manually and up to 50° hydraulically in either direction |
(9 positions manually: Center, 4 clockwise and 4 counterclockwise in 10° increments) (Hydraulically: Any degree up to 50 degrees) Allows the operator to set the blade at the angle of his choice up to 40° to complete the job with satisfactory results. |
| Blade offsets left and right up to 30” | (9 positions manually: Center, 4 positions left and 4 positions right) (Hydraulically: Any position up to 30”) Allows the operator to position the end of the moldboard beyond tractor tire and close to solid obstacles such as fences, buildings and abutments. |
| Blade tilts up and down up to 20° | Allows the operator to do simple tasks such as putting a crown in the middle of a road to making V-type ditches of various sizes. |
| Fully welded main frame (Tubular construction) |
Fully welded adds overall strength and rigidity to blade frame. |
| Heavy-duty pivot assembly with 3” solid steel kingpin |
3/4” Plate steel turntable and 3” kingpin for handling the high amount of torque that can be transferred to this area. |
| Formed 17 inch Moldboard | Precisely formed moldboard rolls dirt and debris with ease. |
| 5/16” Moldboard thickness with box reinforcement |
Thick material with fully welded box reinforcement creates a strong moldboard. |
| Reversible cutting edge | Get twice the wear from the cutting edge by flipping it over. |
| Retractable parking stand | Able to store the unit with the frame off the ground, also aids in attaching to tractor. |
| Skid shoes (optional) | Skid shoes help protect from hitting low obstructions by keeping the moldboard off the ground. |
| End plates (optional) | End plates hold material in and allows it to be moved. |
| Cushion valve (optional) | Helps protect the moldboard and cylinders in the event an obstruction is hit by allowing hydraulic fluid to bypass the cushion valve and flow back towards the tractor. |
Specs
| Model | RBT3584 |
| Blade Width 84" 96" | 84" |
| Approximate Weight (lbs.) with manual links | 709 lbs. |
| Maximum Tractor Horsepower | 80 HP for 2 Wheel Drive and 65 HP for 4 Wheel Drive |
| Maximum G.V.W. (lbs.) | 9500 lbs. |
| Hitch Type | Cat. 1 & 2 Fits Land Pride Quick-Hitch |
| Blade Angle Manual Linkage: Hydraulic Cylinder: |
With blade facing forward or reversed Up to 40° in 10° increments clockwise and counterclockwise Up to 50° clockwise and counterclockwise |
| Angle Cylinder | 3 1/2" X 14" X 1 1/4" |
| Blade Offset Manual Linkage Hydraulic Cylinder |
Up to 30 inches left and right in 9 positions (Center, 4 left and 4 right) Up to 30 inches left and right |
| Offset Cylinder | 3 1/2" X 14" X 1 1/4" |
| Blade Tilt Manual Ratchet Jack Hydraulic Cylinder |
Maximum 20° up and 20° down with blade facing forward or reversed Maximum 20° up and 20° down with blade facing forward or reversed |
| Tilt Cylinder | 2" bore x 6" stroke x 1 1/4" bore |
| Moldboard King Pin | 3" diameter |
| Moldboard Height | 17" tall |
| Moldboard Thickness | 5/16" reinforced, 3/16" tapered reinforcement channel |
| Cutting Edge | 1/2" x 6" Heat treated, Replaceable & Reversible (Double bevel) |
| Main Frame Construction | Fully Welded Tubular Construction |
| Parking Stand | Retractable |
| Accessories | Manual or Hydraulic Single Gauge Wheel, Skid Shoes, End Plates, Hydraulic Selector Valve and Cushion Valve |
