Features
| FEATURES | BENEFITS |
| Quality Comer Gearbox | Provides long life, durability construction. |
| Greasable bearings | Less drag and extends life of unit. |
| Adjustable 3-point hitch | Operator may set the distance between tractor and Snow Blower to his/her preference. |
| Quick Hitch compatible | Makes for faster and easier hook-up to tractor. |
| Large main housing | Ability to handle large drifts. |
| Large impeller diameter | The ability to move and throw material farther. |
| Guarded discharge chute | Guards against operator putting his or her hands into the impeller. |
| Options | |
| Bolt-on reversible lower wear bar |
Protects against wear on the auger housing and improves service life of the Snow Blower. The optional hardened steel wear bar last longer. |
| Gear driven chute rotator | Allows choice of three rotator options: manual drive, electric actuator, or hydraulic motor. |
| Shearbolt protected impeller and auger | Eliminates costly repairs. |
| Three skid shoe options | Multiple surfaces allows you to pick the correct skid shoe for your application. |
Specs
| Model No. | SB1064 |
| Working Width | 64" |
| Overall Width | 65 3/4" |
| Weight without options | 494 lbs. |
| Tractor Horsepower | 18-59 HP |
| 3-Point Hitch & Category | Adjustable Cat. I |
| Quick Hitch Compatible | Yes |
| Main Housing Material | 12 gauge |
| Side Plate Material | 3/16" |
| Chute Opening At Base | 8" |
| Impeller Diameter | 20" |
| Impeller Housing Depth | 6" |
| Number of Impeller Blades | 4 |
| Auger Diameter | 14" |
| Number of Auger Paddles | 4 |
| Gearbox Oil Capacity & Type | 1.06 Pints of SAE90W Gearlube |
| Drive Chain | #60 RC |
| Driveline Category | Cat. ll, Shearbolt protected |
| Driveline Shearbolt | M8 x 50 C1.6.6 |
| Drive Shaft Shearbolt | 1/4" -20 Grade 5 bolt |
| Optional Equipment | |
| Lower Wear Bar Construction | Bolt-on, reversible, and replaceable full length lower wear bar Two options available: Hardened steel wear bar option or steel wear bar option |
| Weight | 14 lbs. |
| Outer Skid Shoe & Weight Outer Wear Bar & Weight Inner Skid Shoe & Weight |
Bolt-on, adjustable & replaceable (8 lbs) Bolt-on, adjustable & replaceable (14 lbs) In-board mounted on the rear, adjustable and replaceable (19 lbs) |
| Chute Rotation & Weight Manual Electric Hydraulic |
Gear & worm drive (10 lbs.) Gear drive (20 lbs.) Gear drive (12 lbs) |
| Deflector & Weight Manual Electric Hydraulic |
Locking bar (2 lbs.) Electric Actuator (25 lbs.) Hydraulic cylinder (32 lbs.) |
