Features
| FEATURES | BENEFITS |
| Quality hydraulic motor | Provides long life, durable construction. |
| Large main housing | Ability to handle large drifts. |
| Large impeller diameter | The ability to move and throw material farther. |
| Bolt-on reversible and replaceable cutting edge |
Improves service life of Snow Blower by protecting the unit from bottom wear and absorbing some of the shock when hitting solid objects. The blade can be rotated 180o to double its life and can be replaced when both edges are worn out. |
| Greaseable auger end bearing | Less drag on the power train and extends life of unit. |
| Side mounted skid shoes | Supports cutting edge above paved, gravel, and rocky surfaces. |
| Sprocket driven chute rotator | Allows operator to change chute rotation angle within a 220 degree discharge pattern. |
| 3/8" Auger Flighting | Stands up to severe use. |
Specs
| Model No. | SBL2566 |
| Working Width | 66 (1.68) |
| Overall Width | 71 1/2 (1.82) |
| Weight with outside skid shoes, case drain line, couplings, & hydraulic motor | 816 (370) |
| Drive and Control System | Hydraulic motors with electric over hydraulic |
| Hydraulic Requirements: Low Volume Motor Option Medium Volume Motor Option High Volume Motor Option |
12-19 (45.4-71.9) 20-26 (75.7-98.4) 27-33 (102.2-124.9) |
| Hydraulic Pressure Rating | 2500-3500 (17.2-24.1) |
| Hitch | Skid steer/loader mounting plate |
| Main Housing Material | 10 (3.4) |
| Side Plate Material | 3/16 (5) |
| Chute Opening at the Base | 10 (25.4) |
| Impeller Housing Depth | 8 (20.3) |
| Impeller Diameter | 24 (61) |
| Number of Impeller Blades | 4 |
| Auger Diameter | 16 (40.6) |
| Number of Auger Paddles | 4 |
| Cutting edge | Bolt-on, reversible, and replaceable full-length cutting edge |
| Skid Shoes | Bolt-on, adjustable & replaceable |
| Chute Rotation | 220 Degrees (Hydraulically driven sprocket) |
| Spout Deflector | Hydraulic operation |
| Spout Deflector Cylinder | Double acting 2 x 4 x 1 1/2 (5.1 x 10.2 x 3.8) rod |
